group: YP6
potable water
heating
cooling
commercial building
WRAS
item number
size
dimensions
weight
packaging
gtin
item number
size
Ø8x6
dimensions
8x10x21 mm
weight
0.01 kg
packaging
bag (10 pce)
gtin
05022050276728
item number
size
Ø10x8
dimensions
10x13x25 mm
weight
0.01 kg
packaging
bag (10 pce)
gtin
05022050276803
item number
size
Ø15x8
dimensions
11x16x31 mm
weight
0.01 kg
packaging
bag (10 pce)
gtin
05022050277046
item number
size
Ø15x10
dimensions
13x16x31 mm
weight
0.01 kg
packaging
bag (10 pce)
gtin
05022050277121
item number
size
Ø15x12
dimensions
15x16x31 mm
weight
0.01 kg
packaging
bag (10 pce)
gtin
05022050277282
item number
size
Ø22x15
dimensions
22x22x40 mm
weight
0.02 kg
packaging
bag (10 pce)
gtin
05022050002884
item number
size
Ø28x15
dimensions
18x28x50 mm
weight
0.04 kg
packaging
bag (10 pce)
gtin
05022050277565
item number
size
Ø28x22
dimensions
25x29x50 mm
weight
0.04 kg
packaging
bag (10 pce)
gtin
05022050277725
item number
size
Ø35x15
dimensions
19x36x55 mm
weight
0.05 kg
packaging
bag (10 pce)
gtin
05022050277862
item number
size
Ø35x22
dimensions
25x35x59 mm
weight
0.06 kg
packaging
bag (10 pce)
gtin
05022050277947
item number
size
Ø35x28
dimensions
31x36x55 mm
weight
0.06 kg
packaging
bag (10 pce)
gtin
05022050278005
item number
size
Ø42x15
dimensions
18x42x70 mm
weight
0.09 kg
packaging
bag (1 pce)
gtin
05022050082091
item number
size
Ø42x22
dimensions
26x43x70 mm
weight
0.1 kg
packaging
bag (1 pce)
gtin
05022050082107
item number
size
Ø42x28
dimensions
32x43x69 mm
weight
0.1 kg
packaging
bag (1 pce)
gtin
05022050082114
item number
size
Ø42x35
dimensions
38x42x66 mm
weight
0.09 kg
packaging
bag (1 pce)
gtin
05022050082121
item number
size
Ø54x15
dimensions
19x54x85 mm
weight
0.16 kg
packaging
bag (1 pce)
gtin
05022050082138
item number
size
Ø54x22
dimensions
26x54x76 mm
weight
0.14 kg
packaging
bag (1 pce)
gtin
05022050082145
item number
size
Ø54x28
dimensions
32x54x80 mm
weight
0.17 kg
packaging
bag (1 pce)
gtin
05022050082152
item number
size
Ø54x35
dimensions
39x55x80 mm
weight
0.15 kg
packaging
bag (1 pce)
gtin
05022050082169
item number
size
Ø54x42
dimensions
46x55x80 mm
weight
0.15 kg
packaging
bag (1 pce)
gtin
05022050082176
item number
size
Ø67x54
dimensions
58x67x90 mm
weight
0.26 kg
packaging
bag (1 pce)
gtin
05022050082213
item number
size
d1
l1
z1
d2
l2
z2
color
copper
materials
copper (CW024A (UNS C12200))
finishing
none
shape
straight
connection type
solder
sealing
Metal sealing
product group
fittings
ETIM class
EC003024 Fitting with 2 connections
HS code
74121000
brand
Pegler
series
Yorkshire
product type
YP6
UNSPS
40173613
max operating pressure liquid
16 bar
min. medium temperature
-40 °C
max medium temperature
110 °C
peak medium temperature
110 °C
label
value
label
ETIM class
label
Surface protection connection 1
value
Untreated
label
Surface treatment connection 1
value
Untreated
label
Surface protection connection 2
value
Untreated
label
Surface treatment connection 2
value
Untreated
label
Shape
value
Straight
label
Model
value
1-part
label
Reducing
value
No
label
Eccentric
value
No
label
System specific
value
Yes
label
Connection 1
value
Soldered sleeve
label
Connection 2
value
Soldered sleeve
label
Main colour fitting
value
Copper
label
Flange compression class (PN)
value
PN 16
label
Material sealing
value
Metal-sealing
label
With buffer stud
value
No
label
Medium temperature (continuous)
value
-40°C - 110°C
label
Medium temperature (continuous) (imperial)
value
-40°F - 230°F
label
Max. operating pressure at 20 °C
value
16bar
label
Max. operating pressure at 20 °C (imperial)
value
232.06psi
label
With thermal insulation
value
No
label
With sealing rings/gaskets
value
No
label
Capped
value
No
label
With drain valve
value
No
label
With de-aerator
value
No
label
FM quality mark
value
No
label
LPCB quality mark
value
No
label
ULC quality mark
value
No
label
UL quality mark
value
No
label
VdS quality mark
value
No
label
DVGW quality mark for gas
value
No
label
DVGW quality mark for water
value
No
label
Certified according to NF 545
value
No
label
KIWA certified
value
No
label
Gastec QA mark
value
No
label
KOMO certified
value
No
label
Gastec QA - AR 214 (H2)
value
No
item number
