group: YP2
potable water
heating
cooling
commercial building
WRAS
item number
size
dimensions
weight
packaging
gtin
item number
size
15xRp1 1/2"
dimensions
20x27x34 mm
weight
0.05 kg
packaging
bag (10 pce)
gtin
05022050272607
item number
size
22xRp3/4"
dimensions
27x32x39 mm
weight
0.07 kg
packaging
bag (10 pce)
gtin
05022050272744
item number
size
28xRp1"
dimensions
33x40x48 mm
weight
0.15 kg
packaging
bag (5 pce)
gtin
05022050272898
item number
size
35xRp1 1/4"
dimensions
41x48x56 mm
weight
0.23 kg
packaging
bag (1 pce)
gtin
05022050080943
item number
size
42xRp1 1/2"
dimensions
49x55x60 mm
weight
0.31 kg
packaging
bag (1 pce)
gtin
05022050080950
item number
size
54xRp2"
dimensions
60x66x70 mm
weight
0.42 kg
packaging
bag (1 pce)
gtin
05022050080967
color
brass
materials
brass (CW603N)
finishing
none
shape
straight
connection type
Rp - female thread cylindrical (BSPT), solder
sealing
Metal sealing
product group
fittings
ETIM class
EC003024 Fitting with 2 connections
HS code
74122000
brand
Pegler
series
Yorkshire
product type
YP2
UNSPS
40172612
max operating pressure liquid
16 bar
min. medium temperature
-40 °C
max medium temperature
110 °C
peak medium temperature
110 °C
label
value
label
ETIM class
label
Surface protection connection 1
value
Untreated
label
Surface treatment connection 1
value
Untreated
label
Surface protection connection 2
value
Untreated
label
Surface treatment connection 2
value
Untreated
label
Shape
value
Straight
label
Model
value
1-part
label
Reducing
value
No
label
Eccentric
value
No
label
System specific
value
Yes
label
Connection 1
value
Internal thread cylindrical BSPT-Rp (ISO 7-1 / EN 10226-1)
label
Connection 2
value
Soldered sleeve
label
Main colour fitting
value
Brass
label
Flange compression class (PN)
value
PN 16
label
Material sealing
value
Metal-sealing
label
With buffer stud
value
No
label
Medium temperature (continuous)
value
-40°C - 110°C
label
Medium temperature (continuous) (imperial)
value
-40°F - 230°F
label
Max. operating pressure at 20 °C
value
16bar
label
Max. operating pressure at 20 °C (imperial)
value
232.06psi
label
With thermal insulation
value
No
label
With sealing rings/gaskets
value
No
label
Capped
value
No
label
With drain valve
value
No
label
With de-aerator
value
No
label
FM quality mark
value
No
label
LPCB quality mark
value
No
label
ULC quality mark
value
No
label
UL quality mark
value
No
label
VdS quality mark
value
No
label
DVGW quality mark for gas
value
No
label
DVGW quality mark for water
value
No
label
Certified according to NF 545
value
No
label
KIWA certified
value
No
label
Gastec QA mark
value
No
label
KOMO certified
value
No
label
Gastec QA - AR 214 (H2)
value
No
