group: BSF-8-10
heating
cooling
residential
commercial building
industry
RAL gütezeichen rohrbefestigung
item number
size
dimensions
weight
packaging
gtin
item number
size
M8-M10 x 13-17.5
dimensions
37x53x20 mm
weight
0.06 kg
packaging
bag (10 pce)
gtin
08719313014001
item number
size
M8-M10 x 21-25.5
dimensions
53x46x20 mm
weight
0.07 kg
packaging
bag (10 pce)
gtin
08719313014025
item number
size
M8-M10 x 26.5-30.5
dimensions
61x52x20 mm
weight
0.08 kg
packaging
bag (10 pce)
gtin
08719313014049
item number
size
M8-M10 x 33.5-38.5
dimensions
68x60x20 mm
weight
0.09 kg
packaging
bag (10 pce)
gtin
08719313014063
item number
size
M8-M10 x 41.5-47
dimensions
76x68x20 mm
weight
0.1 kg
packaging
bag (10 pce)
gtin
08719313014087
item number
size
M8-M10 x 48-54
dimensions
86x80x20 mm
weight
0.11 kg
packaging
bag (10 pce)
gtin
08719313014100
item number
size
M8-M10 x 56-62.5
dimensions
95x84x20 mm
weight
0.12 kg
packaging
bag (10 pce)
gtin
08719313014124
item number
size
M8-M10 x 62.5-69.5
dimensions
104x90x20 mm
weight
0.13 kg
packaging
bag (10 pce)
gtin
08719313014148
item number
size
M8-M10 x 69.5-76.5
dimensions
111x98x20 mm
weight
0.13 kg
packaging
bag (10 pce)
gtin
08719313014162
item number
size
M8-M10 x 77.5-84
dimensions
125x106x20 mm
weight
0.14 kg
packaging
bag (10 pce)
gtin
08719313014186
item number
size
M8-M10 x 85-92.5
dimensions
134x114x20 mm
weight
0.15 kg
packaging
bag (10 pce)
gtin
08719313014209
item number
size
M8-M10 x 93-100.5
dimensions
152x122x20 mm
weight
0.22 kg
packaging
carton (25 pce)
gtin
08719313014216
item number
size
M8-M10 x 101.5-110
dimensions
161x132x20 mm
weight
0.23 kg
packaging
carton (25 pce)
gtin
08719313014223
item number
size
M8-M10 x 110-117.5
dimensions
169x138x20 mm
weight
0.24 kg
packaging
carton (25 pce)
gtin
08719313014230
item number
size
M8-M10 x 119.5-127.5
dimensions
179x148x20 mm
weight
0.26 kg
packaging
carton (25 pce)
gtin
08719313014247
code
size
DN1
item
BSF clip M8/M10
item number with gtin
BSF-8-10
manufacturer
Aalberts integrated piping systems B.V. (VSH)
weight
0.26 kg
dimensions
179x148x20 mm
materials
steel
finishing
galvanized (electrolytically zincplated)
min. medium temperature
-40 °C
max medium temperature
250 °C
product group
Fastening (double screw)
ETIM class
EC010049 Two-part bracket roundHS code
73089098
brand
FastFix
series
clips - unlined
product type
BSF-8-10
label
value
label
etim-class
label
Material
value
Steel
label
Surface protection
value
Galvanic/electrolytic zinc plated
label
Inlay damping value
value
label
Connection facility
value
Internal thread
label
Connection size, connection facility
value
M8/M10
label
Lock facility
value
Double screw
label
Suitable for number of pipes
value
1
label
Height
value
20mm
label
Height (imperial)
value
0.79"
label
FM quality mark
value
No
label
UL quality mark
value
No
label
ULC quality mark
value
No
label
LPCB quality mark
value
No
label
Suitable for steel tube
value
Yes
label
Suitable for stainless steel tube
value
No
label
Suitable for copper tube
value
No
label
Suitable for aluminium tube
value
No
label
Suitable for cast iron pipe
value
Yes
label
Suitable for plastic tube
value
Yes
label
Suitable for pipe coil
value
No
label
Medium temperature (continuous)
value
-40°C - 250°C
label
Medium temperature (continuous) (imperial)
value
-40°F - 482°F
label
VdS quality mark
value
No
label
KIWA certified
value
No
