group: 98LS
heating
commercial building
no approvals available
code
size
dimensions
weight
packaging
gtin
code
size
15x1/2xR1/2
dimensions
30x90x110 mm
weight
0.37 kg
packaging
bag (1 pce)
gtin
05013866018060
code
size
22x3/4xR3/4
dimensions
40x100x135 mm
weight
0.51 kg
packaging
bag (1 pce)
gtin
05013866018091
item
Straight Pattern
item number with gtin
98LS
manufacturer
Aalberts integrated piping systems Ltd (Pegler)
weight
0.51 kg
dimensions
40x100x135 mm
color
chrome
materials
brass, plastic (CW617N, ABS)
finishing
polished chrome
shape
Elbow
connection type
compression, R - male thread gas conical (BSPT)
pressure rating (PN)
PN 10
sealing
EPDM
max operating pressure liquid
10 bar
min. medium temperature
4 °C
max medium temperature
120 °C
peak medium temperature
120 °C
product group
radiator valves (MRV)
ETIM class
EC010136 Radiator valveHS code
84818039
brand
Pegler
series
Belmont Lockshield
product type
98LS
UNSPS
40141609
label
value
label
etim-class
value
EC010136 Radiator valvelabel
Housing material
value
Brass
label
Shape
value
Right-angled
label
Suitable for single pipe system
value
No
label
Suitable for two pipe system
value
No
label
Length of connection 1
value
40mm
label
Length of connection 1 (imperial)
value
1.57"
label
Working length connection 1
value
15mm
label
Working length connection 1 (imperial)
value
0.59"
label
Length of connection 2
value
65mm
label
Length of connection 2 (imperial)
value
2.56"
