group: Z05
heating
cooling
compressed air
sprinkler
dry fire main
vacuum
residential
fire protection
datacenters
utility
industry
CRN
FM
LPCB
QB (CSTBat)
UL
ULc
VdS
item number
size
dimensions
weight
packaging
gtin
item number
size
-
dimensions
46x102x66 mm
weight
0.64 kg
packaging
Carton (1 pce)
gtin
04710574610142
item number
size
-
dimensions
46x109x72 mm
weight
0.66 kg
packaging
Carton (1 pce)
gtin
04710574610197
item number
size
-
dimensions
46x109x72 mm
weight
0.66 kg
packaging
Carton (1 pce)
gtin
04710574610203
item number
size
d1
DN1
l1
z1
d2
DN2
l2
z2
color
silver, orange
materials
cast iron (ASTM A536 65-45-12)
finishing
hot dip galvanized, varnished
shape
straight (0º)
connection type
groove (coupling)
sealing
EPDM
product group
fittings (demountable)
ETIM class
EC003024 Fitting with 2 connections
HS code
73071910
brand
VSH
series
Shurjoint
product type
Z05E
UNSPS
40171704
max operating pressure liquid
35 bar
min. medium temperature
-34 cel
max medium temperature
110 cel
label
value
label
ETIM class
label
Material connection 1
value
Cast iron
label
Material quality connection 1
value
ASTM A536 Grade 65-45-12
label
Material connection 2
value
Cast iron
label
Material quality connection 2
value
ASTM A536 Grade 65-45-12
label
Shape
value
Straight
label
Model
value
2-part
label
Bend angle
value
0°
label
Reducing
value
No
label
Eccentric
value
No
label
System specific
value
No
label
Connection 1
value
Ribbing groove (groove coupling)
label
Connection 2
value
Ribbing groove (groove coupling)
label
Material sealing
value
Ethylene-propylene diene monomer rubber (EPDM)
label
With buffer stud
value
No
label
High tensile strength
value
Yes
label
Length
value
46mm
label
Length (imperial)
value
1.81"
label
Length of connection 1
value
23mm
label
Length of connection 1 (imperial)
value
0.91"
label
Working length connection 1
value
0.6mm
label
Working length connection 1 (imperial)
value
0.02"
label
Length of connection 2
value
23mm
label
Length of connection 2 (imperial)
value
0.91"
label
Working length connection 2
value
0.6mm
label
Working length connection 2 (imperial)
value
0.02"
label
Medium temperature (continuous)
value
-34°C - 110°C
label
Medium temperature (continuous) (imperial)
value
-29.2°F - 230°F
label
Max. operating pressure at 20 °C
value
35bar
label
Max. operating pressure at 20 °C (imperial)
value
507.63psi
label
With sealing rings/gaskets
value
No
label
Capped
value
No
label
With connection indicator
value
No
label
With drain valve
value
No
label
With de-aerator
value
No
label
FM quality mark
value
Yes
label
LPCB quality mark
value
Yes
label
ULC quality mark
value
Yes
label
UL quality mark
value
Yes
label
VdS quality mark
value
Yes
label
DVGW quality mark for gas
value
No
label
DVGW quality mark for water
value
No
label
Certified according to NF 545
value
No
label
KIWA certified
value
No
label
Gastec QA mark
value
No
label
KOMO certified
value
No
label
Gastec QA - AR 214 (H2)
value
No
item number
carbon footprint (A1-A3) cradle-to-gate
carbon footprint (A-C) embodied carbon
carbon footprint (A-D) cradle-to-cradle
data source
item number
10z050015e01carbon footprint (A1-A3) cradle-to-gate
2.67kgCO2e
carbon footprint (A-C) embodied carbon
3.09kgCO2e
carbon footprint (A-D) cradle-to-cradle
2.12kgCO2e
data source
EPD
