group: V907
potable water
natural gas
heating
cooling
commercial building
industry
shipbuilding
no approvals available
item number
size
dimensions
weight
packaging
gtin
item number
size
DN65
dimensions
270x135x253 mm
weight
4.3 kg
packaging
bag (1 pce)
gtin
05022050069221
item number
size
DN80
dimensions
295x180x280 mm
weight
5.26 kg
packaging
bag (1 pce)
gtin
05022050069665
item number
size
DN100
dimensions
380x95x320 mm
weight
7.01 kg
packaging
unpackaged (1 pce)
gtin
05022050070289
item number
size
DN125
dimensions
390x95x350 mm
weight
10.2 kg
packaging
unpackaged (1 pce)
gtin
05022050070722
item number
size
DN150
dimensions
420x90x370 mm
weight
11.7 kg
packaging
unpackaged (1 pce)
gtin
05022050071088
item number
size
DN200
dimensions
620x135x455 mm
weight
23 kg
packaging
unpackaged (1 pce)
gtin
05022050071545
item number
size
d1
DN1
l1
d2
DN2
l2
b2
M1
M2
E
H
h1
Y
V
U
D1
a
item number
15332size
DN65
d1
76.1
DN1
DN65
l1
23
d2
76.1
DN2
DN65
l2
23
b2
50
M1
28
M2
200
E
30
H
222
h1
4
Y
43
V
145
U
66
D1
180
a
90
item number
15333size
DN80
d1
88.9
DN1
DN80
l1
23
d2
88.9
DN2
DN80
l2
23
b2
54
M1
28
M2
200
E
30
H
239
h1
4
Y
43
V
151
U
66
D1
200
a
90
item number
15334size
DN100
d1
114.3
DN1
DN100
l1
26
d2
114.3
DN2
DN100
l2
26
b2
56
M1
35
M2
290
E
44
H
254
h1
4
Y
55
V
175
U
66
D1
220
a
90
item number
15335size
DN125
d1
139.7
DN1
DN125
l1
28
d2
139.7
DN2
DN125
l2
28
b2
62
M1
35
M2
290
E
44
H
262
h1
4
Y
55
V
190
U
90
D1
255
a
90
item number
15336size
DN150
d1
168.3
DN1
DN150
l1
28
d2
168.3
DN2
DN150
l2
28
b2
63
M1
35
M2
290
E
44
H
280
h1
4
Y
55
V
203
U
95
D1
293
a
90
item number
15337size
DN200
d1
219.1
DN1
DN200
l1
30
d2
219.1
DN2
DN200
l2
30
b2
65
M1
47
M2
450
E
69
H
320
h1
4
Y
89
V
245
U
95
D1
330
a
90
color
blue
materials
cast iron (GGG40 (EN-GJS-400-15))
finishing
primer/paint
shape
straight (0º)
connection type
flange
pressure rating (PN)
PN 6
sealing
NBR (Nitrile)
product group
valves (butterfly valves)
ETIM class
EC010910 Butterfly valve
HS code
84813091
brand
Pegler
series
Butterfly Valve
product type
V907
UNSPS
40141619
max operating pressure liquid
6 bar
min. medium temperature
-10 °C
max medium temperature
120 °C
peak medium temperature
85 °C
Kvs-value
label
value
label
ETIM class
value
label
Housing material
value
Cast iron
label
Material quality
value
Cast iron EN-GJS-400-15 (GGG 40)
label
Surface protection
value
Primer
label
Material valve butterfly
value
Stainless steel
label
Material quality valve butterfly
value
Other
label
Standard
value
EN
label
Connections
value
Flange (expired)
label
Article compression class
value
PN 6
label
Flange compression class
value
PN 6
label
Operation
value
Lever handle
label
Sealing
value
NBR (nitrile rubber)
label
Material spindle
value
Stainless steel
label
Material primary spindle seal
value
Ethylene-propylene diene monomer rubber (EPDM)
label
Angle of the valve
value
0°
label
Spindle angle
value
90°
label
Spindle angle (imperial)
value
3.54"
label
Medium temperature (continuous)
value
-10°C - 120°C
label
Medium temperature (continuous) (imperial)
value
14°F - 248°F
label
FM quality mark
value
No
label
UL quality mark
value
No
label
ULC quality mark
value
No
label
LPCB quality mark
value
No
label
VdS quality mark
value
No
label
KIWA certified
value
No
label
Gastec QA mark
value
No
label
Gastec QA - AR 214 (H2)
value
No
