group: TPX300
potable water
heating
non-potable water
commercial building
Watermark
item number
size
dimensions
weight
packaging
gtin
item number
size
16 (DN15)
dimensions
73x28x51 mm
weight
0.2 kg
packaging
-
gtin
05022050609892
item number
size
20 (DN20)
dimensions
88x36x64 mm
weight
0.34 kg
packaging
-
gtin
05022050610058
item number
size
d1
DN1
l1
z1
d2
DN2
l2
z2
M
H
h1
Y
V
U
D1
a
item number
903209size
16 (DN15)
d1
16.0
DN1
DN12
l1
35
z1
11
d2
15.0
DN2
DN12
l2
28
z2
10
M
53
H
38
h1
0
Y
20
V
18
U
21
D1
27
a
90
item number
903215size
20 (DN20)
d1
16.0
DN1
DN12
l1
40
z1
12
d2
14.0
DN2
DN20
l2
178
z2
17
M
53
H
38
h1
0
Y
20
V
18
U
21
D1
27
a
90
color
brass
materials
brass (CW602N (DZR))
finishing
none
shape
straight (0º)
connection type
push
pressure rating (PN)
PN 20
sealing
EPDM
product group
valves (ball valves)
ETIM class
EC011343 Ball valve
brand
VSH
series
Tectite Pacific Ball Valve
product type
TPX300
UNSPS
40141607
max operating pressure liquid
20 bar
min. medium temperature
10 °C
max medium temperature
95 °C
peak medium temperature
95 °C
Kvs-value
value depends on the item view items
label
value
label
ETIM class
value
label
Housing material
value
Brass
label
Material quality
value
CuZn36Pb2As (CW602N)
label
Surface protection housing
value
None
label
Material ball seal
value
Ethylene-propylene diene monomer rubber (EPDM)
label
Material ball
value
Brass
label
Material spindle
value
Brass
label
Material primary spindle seal
value
Ethylene-propylene diene monomer rubber (EPDM)
label
Nominal diameter connection 1
value
DN 12
label
Outer pipe diameter connection 1
value
16mm
label
Outer pipe diameter connection 1 (imperial)
value
0.63"
label
Connection 1
value
Insert (push-fitting)
label
With coupling connection 1
value
No
label
Connection 2
value
Insert (push-fitting)
label
With coupling connection 2
value
No
label
Sealing
value
Ethylene-propylene diene monomer rubber (EPDM)
label
Article compression class
value
PN 20
label
With drain valve
value
No
label
With drain possibility (connection)
value
No
label
With non-return valve
value
No
label
With filter
value
No
label
With thermometer
value
No
label
Model
value
Straight
label
With insulation shell
value
No
label
FM quality mark
value
No
label
UL quality mark
value
No
label
ULC quality mark
value
No
label
LPCB quality mark
value
No
label
Medium temperature (continuous)
value
10°C - 95°C
label
Medium temperature (continuous) (imperial)
value
50°F - 203°F
label
Medically clean
value
No
label
Grease-free
value
No
label
Operation
value
Lever handle
label
Housing construction
value
1-part
label
Full bore
value
Yes
label
Handle height
value
20mm
label
Handle height (imperial)
value
0.79"
label
Angle of the valve
value
0°
label
VdS quality mark
value
No
label
DVGW quality mark for gas
value
No
label
DVGW quality mark for water
value
No
label
KIWA certified
value
No
