group: TDECTRVCPLSSTR
heating
commercial building
no approvals available
item number
size
dimensions
weight
packaging
gtin
item number
size
15xR1/2
dimensions
71x83x87 mm
weight
0.36 kg
packaging
box (1 pce)
gtin
05022050357090
item number
size
15xR1/2
dimensions
71x83x87 mm
weight
0.36 kg
packaging
box (1 pce)
gtin
05022050357236
item number
size
15xR1/2
dimensions
71x83x87 mm
weight
0.36 kg
packaging
box (1 pce)
gtin
05022050357335
color
chrome
materials
plastic, brass (CW617N, ABS)
finishing
polished chrome
shape
Elbow
connection type
compression, R - male thread gas conical (BSPT)
sealing
EPDM
product group
radiator valves (TRV)
ETIM class
EC010136 Radiator valve
brand
Pegler
series
Terrier Decorative
product type
TDECTRVCPLSSTR
UNSPS
40141609
max operating pressure liquid
10 bar
min. medium temperature
4 °C
max medium temperature
120 °C
peak medium temperature
120 °C
label
value
label
ETIM class
value
label
Housing material
value
Brass
label
Shape
value
Right-angled
label
Operation
value
Manually operated
label
Suitable for single pipe system
value
No
label
Suitable for two pipe system
value
No
label
Length of connection 1
value
35mm
label
Length of connection 1 (imperial)
value
1.38"
label
Working length connection 1
value
17mm
label
Working length connection 1 (imperial)
value
0.67"
label
Length of connection 2
value
63mm
label
Length of connection 2 (imperial)
value
2.48"
label
Working length connection 2
value
49mm
label
Working length connection 2 (imperial)
value
1.93"
label
Height
value
87mm
label
Height (imperial)
value
3.43"
item number
carbon footprint (A-C) embodied carbon
data source
840109
841006
854266
