group: SRAR
potable water
heating
non-potable water
commercial building
Watermark
item number
size
dimensions
weight
packaging
gtin
item number
size
16xG5/8xG1/2x16xG5/8
dimensions
250x67x81 mm
weight
0.51 kg
packaging
-
gtin
05022050636584
item number
size
16xG5/8xG1/2x16xG5/8
dimensions
350x67x81 mm
weight
0.59 kg
packaging
-
gtin
05022050636614
item number
size
d1
DN1
l1
z1
d2
DN2
l2
z2
d3
DN3
z3
DN4
l4
d5
DN5
z5
angle
item number
903243size
16xG5/8xG1/2x16xG5/8
d1
16.0
DN1
DN12
l1
44
z1
15
d2
16.0
DN2
DN12
l2
44
z2
15
d3
22.0
DN3
1/2" (DN15)
z3
8
DN4
1 1/4" (DN32)
l4
42
d5
22.0
DN5
1/2" (DN15)
z5
8
angle
90
item number
903244size
16xG5/8xG1/2x16xG5/8
d1
16.0
DN1
DN12
l1
25
z1
1
d2
16.0
DN2
DN12
l2
25
z2
1
d3
23.0
DN3
1/2" (DN15)
z3
10
DN4
1 1/4" (DN32)
l4
42
d5
23.0
DN5
1/2" (DN15)
z5
10
angle
90
color
brass
materials
brass (CW602N (DZR))
finishing
none
shape
Perpendicular (90º)
connection type
push, G - female thread gas cylindrical (BSPP), G - male thread gas cylindrical (BSPP)
sealing
EPDM
product group
fittings (demountable)
ETIM class
EC003099 Wall plate
brand
VSH
series
Tectite Pacific
product type
SRAR
UNSPS
40141761
max operating pressure liquid
20 bar
min. medium temperature
10 °C
max medium temperature
95 °C
peak medium temperature
95 °C
label
value
label
ETIM class
value
label
Housing material
value
Brass
label
Surface protection
value
Untreated
label
System specific
value
No
label
Nominal diameter connection 1
value
DN 12
label
Outer pipe diameter connection 1
value
16mm
label
Outer pipe diameter connection 1 (imperial)
value
0.63"
label
Nominal diameter connection 2
value
DN 12
label
Outer pipe diameter connection 2
value
16mm
label
Outer pipe diameter connection 2 (imperial)
value
0.63"
label
Connection
value
Insert (push-fitting)
label
Wall thickness, connection 1
value
1.2mm
label
Wall thickness, connection 1 (imperial)
value
0.05"
label
Wall thickness, connection 2
value
1.2mm
label
Wall thickness, connection 2 (imperial)
value
0.05"
label
Length from wall plate
value
81mm
label
Medium temperature (continuous)
value
10°C - 95°C
label
Medium temperature (continuous) (imperial)
value
50°F - 203°F
label
Max. operating pressure at 20 °C
value
20bar
label
Max. operating pressure at 20 °C (imperial)
value
290.08psi
label
With connection indicator
value
No
label
With protective cap
value
No
label
DVGW quality mark for gas
value
No
label
DVGW quality mark for water
value
No
label
KIWA certified
value
No
label
Gastec QA mark
value
No
label
KOMO certified
value
No
label
Gastec QA - AR 214 (H2)
value
No
