group: K915X
potable water
heating
cooling
commercial building
BSI Kitemark
KIWA
WRAS
item number
size
dimensions
weight
packaging
gtin
item number
size
12
dimensions
21x39x39 mm
weight
0.08 kg
packaging
bag (5 pce)
gtin
05022050096838
item number
size
15
dimensions
25x45x45 mm
weight
0.12 kg
packaging
bag (5 pce)
gtin
05022050096951
item number
size
18
dimensions
25x50x50 mm
weight
0.16 kg
packaging
bag (5 pce)
gtin
05022050097194
item number
size
22
dimensions
33x53x53 mm
weight
0.2 kg
packaging
bag (5 pce)
gtin
05022050097255
item number
size
28
dimensions
40x62x62 mm
weight
0.29 kg
packaging
bag (5 pce)
gtin
05022050097378
item number
size
35
dimensions
46x70x70 mm
weight
0.45 kg
packaging
bag (1 pce)
gtin
05022050097484
item number
size
54
dimensions
72x100x140 mm
weight
1.26 kg
packaging
bag (1 pce)
gtin
05022050097668
color
brass
materials
brass (CW602N (DZR))
finishing
none
shape
Elbow
connection type
compression
sealing
Brass
product group
fittings (demountable)
ETIM class
EC003024 Fitting with 2 connections
HS code
74122000
brand
VSH
series
Kuterlite K900 Pro
product type
K915X
UNSPS
40172801
scip
8959546f-c4a2-4234-89bb-61813ff739d7
max operating pressure liquid
20 bar
min. medium temperature
-15 °C
max medium temperature
90 °C
peak medium temperature
120 °C
label
value
label
ETIM class
label
Material connection 1
value
Brass
label
Material quality connection 1
value
CuZn36Pb2As (CW602N)
label
Surface protection connection 1
value
Untreated
label
Surface treatment connection 1
value
Untreated
label
Material connection 2
value
Brass
label
Material quality connection 2
value
CuZn36Pb2As (CW602N)
label
Surface protection connection 2
value
Untreated
label
Surface treatment connection 2
value
Untreated
label
Shape
value
Bend
label
Model
value
1-part
label
Reducing
value
No
label
Eccentric
value
No
label
System specific
value
No
label
Connection 1
value
Compression ring
label
Connection 2
value
Compression ring
label
Main colour fitting
value
Brass
label
Material sealing
value
Brass
label
With buffer stud
value
No
label
Medium temperature (continuous)
value
30°C - 90°C
label
Medium temperature (continuous) (imperial)
value
86°F - 194°F
label
Max. operating pressure at 20 °C
value
20bar
label
Max. operating pressure at 20 °C (imperial)
value
290.08psi
label
With thermal insulation
value
No
label
With sealing rings/gaskets
value
No
label
Capped
value
No
label
With drain valve
value
No
label
With de-aerator
value
No
label
FM quality mark
value
No
label
LPCB quality mark
value
No
label
ULC quality mark
value
No
label
UL quality mark
value
No
label
VdS quality mark
value
No
label
DVGW quality mark for gas
value
No
label
DVGW quality mark for water
value
No
label
Certified according to NF 545
value
No
label
Gastec QA mark
value
No
label
KOMO certified
value
No
label
Gastec QA - AR 214 (H2)
value
No
