potable water
commercial building
WRAS
item number
size
dimensions
weight
packaging
gtin
item number
size
20x20xRp1/2"
dimensions
31x45x75 mm
weight
0.19 kg
packaging
bag (5 pce)
gtin
05022050044334
item number
size
25x25xRp1/2"
dimensions
38x53x82 mm
weight
0.29 kg
packaging
bag (1 pce)
gtin
05022050672599
item number
size
25x25xRp3/4"
dimensions
38x54x90 mm
weight
0.33 kg
packaging
bag (1 pce)
gtin
05022050672513
item number
size
32x32xRp1"
dimensions
45x65x104 mm
weight
0.5 kg
packaging
bag (1 pce)
gtin
05022050672520
color
brass
materials
brass (CW602N (DZR))
finishing
none
shape
T-piece (90º)
connection type
compression, Rp - female thread cylindrical (BSPT)
sealing
Metal sealing
product group
fittings (demountable)
ETIM class
EC003025 Fitting with 3 connections
HS code
74122000
brand
VSH
series
Kuterlite K700
product type
K730
UNSPS
40174601
scip
8959546f-c4a2-4234-89bb-61813ff739d7
max operating pressure liquid
12 bar
min. medium temperature
20 °C
max medium temperature
20 °C
peak medium temperature
20 °C
label
value
label
ETIM class
label
Material connection 1
value
Brass
label
Material quality connection 1
value
CuZn36Pb2As (CW602N)
label
Surface protection connection 1
value
Untreated
label
Surface treatment connection 1
value
Untreated
label
Material connection 2
value
Brass
label
Material quality connection 2
value
CuZn36Pb2As (CW602N)
label
Surface protection connection 2
value
Untreated
label
Surface treatment connection 2
value
Untreated
label
Material connection 3
value
Brass
label
Material quality connection 3
value
CuZn36Pb2As (CW602N)
label
Model
value
T-piece
label
Angle
value
90°
label
Reducing
value
No
label
Multi-part
value
No
label
System specific
value
No
label
Connection 1
value
Compression ring
label
Connection 2
value
Internal thread cylindrical BSPT-Rp (ISO 7-1 / EN 10226-1)
label
Flange compression class
value
PN 10
label
Material sealing
value
Metal-sealing
label
Main colour fitting
value
Brass
label
Max. operating pressure at 20 °C
value
12bar
label
Max. operating pressure at 20 °C (imperial)
value
174.05psi
label
Medium temperature (continuous)
value
20°C - 20°C
label
Medium temperature (continuous) (imperial)
value
68°F - 68°F
label
With sealing rings/gaskets
value
No
label
With drain valve
value
No
label
With de-aerator
value
No
label
With thermal insulation
value
No
label
With buffer stud
value
No
label
Capped
value
No
label
FM quality mark
value
No
label
LPCB quality mark
value
No
label
ULC quality mark
value
No
label
UL quality mark
value
No
label
VdS quality mark
value
No
label
DVGW quality mark for gas
value
No
label
DVGW quality mark for water
value
No
label
KIWA certified
value
No
label
Gastec QA mark
value
No
label
KOMO certified
value
No
label
Gastec QA - AR 214 (H2)
value
No
item number
