group: K716
potable water
commercial building
WRAS
item number
size
dimensions
weight
packaging
gtin
item number
size
20xR1 1/2"
dimensions
32x49x54 mm
weight
0.13 kg
packaging
bag (5 pce)
gtin
05022050044082
item number
size
25xR3/4"
dimensions
38x58x63 mm
weight
0.23 kg
packaging
bag (5 pce)
gtin
05022050044099
item number
size
32xR1"
dimensions
46x65x75 mm
weight
0.34 kg
packaging
bag (1 pce)
gtin
05022050671196
color
brass
materials
brass (CW602N (DZR))
finishing
none
shape
Elbow
connection type
compression, R - male thread gas conical (BSPT)
sealing
Metal sealing
product group
fittings (demountable)
ETIM class
EC003024 Fitting with 2 connections
HS code
74122000
brand
VSH
series
Kuterlite K700
product type
K716
UNSPS
40172801
scip
8959546f-c4a2-4234-89bb-61813ff739d7
max operating pressure liquid
12 bar
min. medium temperature
20 °C
max medium temperature
20 °C
peak medium temperature
20 °C
label
value
label
ETIM class
label
Material connection 1
value
Brass
label
Material quality connection 1
value
CuZn36Pb2As (CW602N)
label
Surface protection connection 1
value
Untreated
label
Surface treatment connection 1
value
Untreated
label
Material connection 2
value
Brass
label
Material quality connection 2
value
CuZn36Pb2As (CW602N)
label
Surface protection connection 2
value
Untreated
label
Surface treatment connection 2
value
Untreated
label
Shape
value
Bend
label
Model
value
1-part
label
Reducing
value
No
label
Eccentric
value
No
label
System specific
value
No
label
Connection 1
value
Compression ring
label
Connection 2
value
External thread conical BSPT-R (ISO 7-1 / EN 10226-1)
label
Main colour fitting
value
Brass
label
Flange compression class (PN)
value
PN 10
label
Material sealing
value
Metal-sealing
label
Medium temperature (continuous)
value
20°C - 20°C
label
Medium temperature (continuous) (imperial)
value
68°F - 68°F
label
Max. operating pressure at 20 °C
value
12bar
label
Max. operating pressure at 20 °C (imperial)
value
174.05psi
label
With thermal insulation
value
No
label
With sealing rings/gaskets
value
No
label
Capped
value
No
label
With drain valve
value
No
label
With de-aerator
value
No
label
FM quality mark
value
No
label
LPCB quality mark
value
No
label
ULC quality mark
value
No
label
UL quality mark
value
No
label
VdS quality mark
value
No
label
DVGW quality mark for gas
value
No
label
DVGW quality mark for water
value
No
label
Certified according to NF 545
value
No
label
KIWA certified
value
No
label
Gastec QA mark
value
No
label
KOMO certified
value
No
label
Gastec QA - AR 214 (H2)
value
No
