group: BSM
potable water
natural gas
heating
cooling
compressed air
vacuum
residential
commercial building
industry
RAL gütezeichen rohrbefestigung
item number
size
dimensions
weight
packaging
gtin
item number
size
M8-M10 x 12-14
dimensions
44x60x20 mm
weight
0.06 kg
packaging
carton (50 pce)
gtin
08719313012359
item number
size
DN1
z3
materials
steel
finishing
galvanized (electrolytically zincplated)
product group
Fastening (double screw)
ETIM class
EC010049 Two-part bracket round
HS code
73089098
brand
IPS FlamcoFix
series
Fastening clips
product type
BSM
min. medium temperature
-40 °C
max medium temperature
120 °C
label
value
label
ETIM class
label
Material
value
Steel
label
Surface protection
value
Galvanic/electrolytic zinc plated
label
Outer pipe diameter
value
12mm - 14mm
label
Inlay damping value
value
17dB(A)
label
Permitted work load
value
1000N
label
Connection facility
value
Internal thread
label
Connection size, connection facility
value
M8/M10
label
Lock facility
value
Double screw
label
Suitable for number of pipes
value
1
label
Width
value
60mm
label
Width (imperial)
value
2.36"
label
Height
value
20mm
label
Height (imperial)
value
0.79"
label
Depth
value
44mm
label
Depth (imperial)
value
1.73"
label
FM quality mark
value
No
label
UL quality mark
value
No
label
ULC quality mark
value
No
label
LPCB quality mark
value
No
label
Suitable for steel tube
value
Yes
label
Suitable for stainless steel tube
value
Yes
label
Suitable for copper tube
value
Yes
label
Suitable for cast iron pipe
value
Yes
label
Suitable for plastic tube
value
Yes
label
Suitable for pipe coil
value
No
label
Medium temperature (continuous)
value
-40°C - 120°C
label
Medium temperature (continuous) (imperial)
value
-40°F - 248°F
label
VdS quality mark
value
No
label
KIWA certified
value
No
