group: 807
potable water
commercial building
no approvals available
item number
size
dimensions
weight
packaging
gtin
item number
size
15xG1/2 Cr
dimensions
50x20x45 mm
weight
0.1 kg
packaging
box (25 pce)
gtin
05013866007354
color
chrome
materials
brass (CW617N)
finishing
chromed
shape
Elbow (0º)
connection type
compression, G - female thread gas cylindrical (BSPP)
pressure rating (PN)
PN 16
sealing
NBR (Nitrile)
product group
valves (ball valves)
ETIM class
EC011343 Ball valve
HS code
84818099
brand
Pegler
series
Service Valve
product type
807
UNSPS
40141607
max operating pressure liquid
16 bar
min. medium temperature
30 °C
max medium temperature
120 °C
peak medium temperature
120 °C
label
value
label
ETIM class
value
label
Housing material
value
Brass
label
Material quality
value
CuZn40Pb2 (CW617N)
label
Surface protection housing
value
Chromium-plated
label
Material ball
value
Brass
label
Material spindle
value
Brass
label
Material primary spindle seal
value
NBR (nitrile rubber)
label
Nominal diameter connection 1
value
DN 15
label
Connection 1
value
Compression ring
label
With coupling connection 1
value
No
label
Nominal diameter connection 2
value
DN 15
label
Connection 2
value
Internal thread cylindrical BSPP-G (ISO 228-1)
label
With coupling connection 2
value
No
label
Sealing
value
NBR (nitrile rubber)
label
Article compression class
value
PN 16
label
Flange compression class
value
PN 16
label
With drain valve
value
No
label
With drain possibility (connection)
value
No
label
With non-return valve
value
No
label
With filter
value
No
label
With thermometer
value
No
label
With insulation shell
value
No
label
FM quality mark
value
No
label
UL quality mark
value
No
label
ULC quality mark
value
No
label
LPCB quality mark
value
No
label
Medium temperature (continuous)
value
30°C - 120°C
label
Medium temperature (continuous) (imperial)
value
86°F - 248°F
label
Medically clean
value
No
label
Grease-free
value
No
label
Housing construction
value
1-part
label
Full bore
value
Yes
label
Length of connection 1
value
45mm
label
Length of connection 1 (imperial)
value
1.77"
label
Working length connection 1
value
26mm
label
Working length connection 1 (imperial)
value
1.02"
label
Length of connection 2
value
37mm
label
Length of connection 2 (imperial)
value
1.46"
label
Working length connection 2
value
24mm
label
Working length connection 2 (imperial)
value
0.94"
label
Angle of the valve
value
0°
label
Wrench width union nut
value
24mm
label
Wrench width union nut (imperial)
value
0.94"
label
VdS quality mark
value
No
label
DVGW quality mark for gas
value
No
label
DVGW quality mark for water
value
No
label
KIWA certified
value
No
