group: 1031
potable water
heating
steam
compressed air
commercial building
industry
no approvals available
item number
size
dimensions
weight
packaging
gtin
item number
size
G1/2
dimensions
115x25x55 mm
weight
0.39 kg
packaging
box (10 pce)
gtin
05013866001680
item number
size
G3/4
dimensions
115x20x70 mm
weight
0.54 kg
packaging
box (5 pce)
gtin
05013866001697
item number
size
G1
dimensions
140x20x80 mm
weight
0.87 kg
packaging
box (5 pce)
gtin
05013866001703
item number
size
G1 1/4
dimensions
165x30x90 mm
weight
1.4 kg
packaging
box (2 pce)
gtin
05013866001710
item number
size
G1 1/2
dimensions
190x40x100 mm
weight
1.85 kg
packaging
box (2 pce)
gtin
05013866001727
item number
size
G2
dimensions
235x105x195 mm
weight
2.82 kg
packaging
box (1 pce)
gtin
05013866001734
item number
size
d1
DN1
l1
z1
slw1
d2
DN2
l2
z2
slw2
M
H
Y
V
U
a
item number
112007size
G1/2
d1
29.0
DN1
1/2" (DN15)
l1
29
z1
19
slw1
29
d2
29.0
DN2
1/2" (DN15)
l2
29
z2
19
slw2
29
M
70
H
95
Y
17
V
57
U
31
a
90
item number
112008size
G3/4
d1
36.0
DN1
3/4" (DN20)
l1
33
z1
22
slw1
36
d2
36.0
DN2
3/4" (DN20)
l2
33
z2
22
slw2
36
M
70
H
100
Y
17
V
62
U
33
a
90
item number
112009size
G1
d1
42.0
DN1
1" (DN25)
l1
39
z1
27
slw1
42
d2
42.0
DN2
1" (DN25)
l2
39
z2
27
slw2
42
M
85
H
115
Y
20
V
75
U
40
a
90
item number
112010size
G1 1/4
d1
51.0
DN1
1 1/4" (DN32)
l1
45
z1
30
slw1
51
d2
51.0
DN2
1 1/4" (DN32)
l2
45
z2
30
slw2
51
M
85
H
138
Y
23
V
98
U
49
a
90
item number
112011size
G1 1/2
d1
57.0
DN1
1 1/2" (DN40)
l1
50
z1
35
slw1
57
d2
57.0
DN2
1 1/2" (DN40)
l2
50
z2
35
slw2
57
M
105
H
159
Y
26
V
119
U
57
a
90
item number
112012size
G2
d1
72.0
DN1
2" (DN50)
l1
61
z1
47
slw1
72
d2
72.0
DN2
2" (DN50)
l2
61
z2
47
slw2
72
M
105
H
170
Y
26
V
126
U
69
a
90
color
brass
materials
bronze (EN CC499K)
finishing
none
shape
straight (0º)
connection type
G - female thread gas cylindrical (BSPP)
pressure rating (PN)
PN 32
sealing
PTFE
product group
valves (stop valves)
ETIM class
EC010120 Globe valve
HS code
84818079
brand
Pegler
series
Globe Valve
product type
1031
UNSPS
40141611
max operating pressure liquid
32 bar
min. medium temperature
-10 °C
max medium temperature
100 °C
peak medium temperature
198 °C
Kv-value
label
value
label
ETIM class
value
label
Housing material
value
Bronze
label
Connection 1
value
Internal thread cylindrical BSPP-G (ISO 228-1)
label
With coupling connection 1
value
No
label
Connection 2
value
Internal thread cylindrical BSPP-G (ISO 228-1)
label
With coupling connection 2
value
No
label
Article compression class
value
PN 32
label
Medium temperature (continuous)
value
-10°C - 100°C
label
Medium temperature (continuous) (imperial)
value
14°F - 212°F
label
Surface protection
value
Untreated
label
Spindle and/or hand wheel rising
value
No
label
Operation
value
Hand wheel
label
With position indicator
value
No
label
With drain valve
value
No
label
Angle of the valve
value
0°
label
Spindle angle
value
90°
label
Spindle angle (imperial)
value
3.54"
label
Material primary spindle seal
value
PTFE/FPM
label
Suitable for liquids
value
Yes
label
Suitable for gases
value
No
label
Suitable for steam
value
Yes
label
VdS quality mark
value
No
label
KIWA certified
value
No
label
Gastec QA mark
value
No
label
Gastec QA - AR 214 (H2)
value
No
item number
